Microinverter

Ant-800G1

800W Rated Output Power
Remote WiFi monitor
IP67 protection degree
Individual MPPT tracking
Support parallel operation
Cost-effective easy operation
High reliability and efficiency up to 96%

Why choose us?

We have rich service experience and research and development technology.

Stable supply chain

Having our own battery pack and inverter factories with more than 3GWh of Li-FePO4 battery packs and 100000 inverters capacity.

Local Services

Branch offices, technical centers and warehouses in main markets to cover the surrounding area of 200-300 kilometers.

Accept Customization

Supporting OEM and ODM for strategic customers, customers with the same idea, and customers who reach the MOQ.

Excellent After-sales Service

The service & technical team of more than 90 people provides timely assistance, product training and on-site technical support.

Strong R&D Team

The R&D team of more than 30 professionals, who have more than 10 years of R&D experience at top companies in the industry.

Competitive Payment Terms

Supporting a variety of payment methods, such as T/T, L/C, Alibaba Trade Guarantee Payment, paypal, alipay and so on.

Technical Data

Model	Ant-800G1-US	Ant-800G1-EU
Input (DC)
Recommended Input Power (Wp)	210 to 500W+ (2 Pieces)
Max. Input DC Voltage (Vdc)	60
MPPT Voltage Range (Vdc)	25~55	20~55
Start-up Voltage (Vdc)	20
Max. Input Current (A)	13.5×2
Max. DC Short Circuit Current (A)	16.5×2
Output (AC)
Rated Output Power (W)	800
Max. Output Current (A)	4	3.5
Nominal Grid Voltage (V)	220	230
Grid Voltage Range (V)	184~253
Nominal Frequency (Hz)	60	50
Frequency Range (Hz)	55~65	45~55
Power Factor	0.99(default),-0.95(lagging),+0.95(leading)
Maximum Units per Branch	4
Efficiency
CEC Weighted Efficiency	95.50%
Peak Inverter Efficiency	96.00%
MPPT Track Efficiency	>99.50%
Night Time Power Consumption (mW)	<50
Mechanical Data
Operation Temperature Range (°C)	-40~65
Dimension (mm)	260Wx225Hx32D
Weight (kg)	2.9
Cooling	Natural cooling
Noise (dB)	<15
Protection Degree	IP67
General
Display	LED, APP
Communication	Built-in Wifi
Compliance	IEC 62109,IEC 61000,VDE4105

Our gallery

Product Details

Different powers meet the vast majority of scenarios. We provide on-site installation and usage guidance services, making it easy for you to buy and use.

Product Introduction

If you have any questions during the browsing process, please feel free to contact us and communicate with us at any time.

IP67 Protection Degree

Chisage ESS microinverter is designed with an IP67 protection degree, ensuring excellent resistance to dust and water. It is well-suited for outdoor installations, providing reliable performance even in challenging environments.

Individual MPPT Tracking

Each microinverter is equipped with independent Maximum Power Point Tracking (MPPT) function that tracks and optimizes the output of the solar panels in real time to maximize power generation efficiency.

Unleash the potential for unlimited possibilities!

Click to learn more about us and move towards a new era of energy together!

Application Cases

We have served thousands of customers and have rich service experience.

Dubai Installation Case

12kW Solar Energy Storage System in Dubai

South Africa Installation Case

12kW Solar Energy Storage System in South Africa

What Our Customers Have to Say

Real feedback from users can better reflect the professionalism of our products.

We have been looking for a reliable solution for home energy storage and CHISAGE ESS products meet our requirements. Their home energy storage systems have surprised us a lot in terms of performance and we are satisfied with CHISAGE ESS products.

Eren HillPurchasing

It has always been a pleasure for me to be a CHISAGE ESS distributor. The excellent quality of their products and some of their market-leading features have made my sales efforts much smoother, and customers have responded positively to CHISAGE ESS's energy storage solutions.

Cody JoynerGeneral Manager

Our energy needs are increasing and CHISAGE ESS's energy storage solutions provide us with the ideal solution. What I admire is their professional technical support team, who always solves our problems in a timely manner.

Emanuel SadlerOperations Director

FAQ

Most frequent questions and answers

Is your hybrid inverter suitable for most batteries on the market? Has it been tested?

Yes, CHISAGE ESS inverter is compatible with a wide range of batteries available on the market. We have conducted extensive testing to ensure its compatibility and performance. We have a list of all the suitable batteries, please refer to our documentation.

Are you a factory or a trading company?

CHISAGE ESS is a factory 50 kilometers away from Ningbo port, which is very convenient for loading and shipping, and saves a lot of transportation cost. We have a R&D and engineering team of more than 30 people for energy storage systems and solar inverter technology. Now we have over 3GWh of Li-FePO4 battery packs and 100000 inverters capacity.

What’s the payment term?

CHISAGE ESS supports a variety of payment methods, such as T/T, L/C, Alibaba Trade Guarantee Payment, paypal, alipay and others. If we enter into strategic cooperation, we can communicate with you about payment methods such as DP.

What is your sample policy?

CHISAGE ESS welcomes you to test our quality by sample. Samples will be prepared and sent out within 7 working days after the specification is confirmed.
